16mm Normal Open Vandal Proof Push Button Momentary
Negotiable
MOQ
Negotiable
Price
16mm Normal Open Vandal Proof Push Button Momentary
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wenzhou, China
Brand Name: YUESHUN
Certification: CE RoHS
Model Number: JS16B-10/S
High Light:

16mm vandal proof push button

,

Normal Open vandal proof push button

,

16mm anti vandal momentary switch

Payment & Shipping Terms
Packaging Details: The product is packed in foam box to prevent damage during transportation.
Delivery Time: 3-7 work days
Payment Terms: T/T to our company account or by paypal
Supply Ability: 5000Pcs/Day
Specifications
Max. Current: 2A
Max. Voltage: 36V DC
Color: Silver
Body Material: Stainless Steel
Operation Type: Momentary
Operating Temperature: -20℃~+55℃
Product Description

Momentary Metal Anti Vandal Push Button Switch 16mm Ball Round Head Normal open waterproof



Product Feature

- These push buttons switches are perfect for Horn Button Switch, PC Power Switch, Kill Switch or any circuit controls. Also great for electronic DIY projects
- This is Metal push button,which is durable for longstanding press, not easily damaged. You can ask for the fllowing materials: stainless steel, Gold plated brass , Nickel Plated Brass, Zn-Al Alloy.
- Momentary Switch: Press the button switch, it works ; Press the button again ,switch stops working .



Product Specification

  Model Number   JS16B-10/S
  Mounting Hole   16mm
  Max.Switch Rating   Ith:2A Ui:36V DC
  Material   Body Material: Stainless Steel
  Button Material: Stainless Steel
  Contact Material: Silver Alloy
  Base Material: PBT
  The Front Shape   Ball Round Head
  Terminal Type   Screw Termlmal
  Switch Operation   Momentary
  Contact Configuration   Normal Open or Normal Closed all can be customized.
  Mounting panel thickness   1-6 mm
  Operation Distance   About 1.5 mm
  Protection Level   IP65
  Operating Temp   -20℃~+55℃
  Mechanical life:   More than1,000,000 cycles
  Electrical life:   More than 200,000 cycles



Size

16mm Normal Open Vandal Proof Push Button Momentary 0
