Oxidized Aluminum Ring symbol led Illuminated Anti Vandal Push Button Switch 1NO 1NC self-lock silver alloy
- Push buttons are available with normally open and normally closed contacts that change state when the actuator is operated. Momentary switches require the user to keep holding the button for an action to take place, this action is then reset once the button is released. Latching push buttons keep the switch in the set contact state until the button is pressed again.
- Enclosure Material: Black Oxidized Aluminum;High quality metal material & IP65 waterproof protection can be used in wet or dusty enviroment.
- Latching type power buttons : Push it–on, push it again-off;
- Momentary type power buttons: Push it- on, release - the actuator surface spring to original position.
|Ith : 5A Ui : 250V AC
|Body Material : Aluminum
|Button Material : Aluminum
|Contact Material : Silver Alloy
|Base Material : PBT
|The Front Shape
|Flat Round Head
|Pin Termlmal( 2.8 * 0.5 MM )
|Momentary or Latching are available
|1NO + 1NC or 2NO + 2NC
|Mounting panel thickness
|About 2.8 mm
|Led Type : Ring Symbol
| LED Color :
Red,Green,Yellow,Orange,Blue,White,Purple or Double color mixing all Can be customized.
| Led Voltage:
3V 6V 12V 24V 36V 110V 220V 360V for choose.
|LED Life : More than 40,000 hours
