Waterproof ISO9001 Metal 2pin Vandal Proof Push Button
Negotiable
MOQ
Negotiable
Price
Waterproof  ISO9001 Metal  2pin Vandal Proof Push Button
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wenzhou, China
Brand Name: YUESHUN
Certification: CE RoHS
Model Number: JSBS
High Light:

2pin vandal proof push button

,

2pin vandal resistant switch

,

Metal vandal proof push button

Payment & Shipping Terms
Packaging Details: The product is packed in foam box to prevent damage during transportation.
Delivery Time: 3-7 work days
Payment Terms: T/T to our company account or by paypal
Supply Ability: 5000Pcs/Day
Specifications
Max. Current: 2A
Max. Voltage: 36V DC
Color: Silver
Body Material: Stainless Steel
Operation Type: Momentary
Operating Temperature: -20℃~+55℃
Product Description

Momentary Metal Anti Vandal Push Button Switch 16mm Ball Round Head Normal open waterproof



1. This series product,operating part and middle connection adopt conveninet and quick installation way.It canbe used under every terrible condition because of thelock, fall and vibration resistance.

2. The contact is a self-cleaning flat pressing quick action structure;The switch base can be assembled by building blocks, and can combine up to 8 switch elements according to requirements, which can meet the requirements of various specific control circuits.



Product Feature

- These push buttons switches are perfect for Horn Button Switch, PC Power Switch, Kill Switch or any circuit controls. Also great for electronic DIY projects
- This is Metal push button,which is durable for longstanding press, not easily damaged. You can ask for the fllowing materials: stainless steel, Gold plated brass , Nickel Plated Brass, Zn-Al Alloy.
- Momentary Switch: Press the button switch, it works ; Press the button again ,switch stops working .



Product Specification

Metal Push Button Switch With Led
Mounting hole size : 16mm,19mm,22mm
Switch value: 2A/36V DC, 5A/250V AC
Operation type: Momentary, Latching
Contact configuration: 1NO,1NC,1NO1NC,2NO2NC,3NO3NC
Hear shape: Domed,High,Flat
Crust material: Stainless Steel, Nickel-plated brass, Aluminum alloy
Terminal type: Pin terminal, Screw terminal
Electrical life : ≥50,000 times
Mechanical life: ≥1,000,000 times
Operation temperature: -40℃~+80℃
Contact Resistance: ≤50mΩ
Insulation Resistance: ≥1000mΩ
Operation stroke: 2.5m
IP Class: IP65,Ik08
Contact material: Silver alloy
Illumination type: Ring illumination,Dot illuminated, Ring illumination and illuminated Power symbol
Led color: R G B O W Y (One led)
  Red/Green,Red/Blue,Red/White bi-color led
  Red-Green-Blue tri-color led
Led voltage: 2V(3V),5V(6V),12V,24V,36V,110V,220V
Led life: 50,000 hours



Size

Waterproof  ISO9001 Metal  2pin Vandal Proof Push Button 0
