Momentary Illuminated Push Switch Power Button 1NO 1NC With Pin Terminal
Negotiable
MOQ
Negotiable
Price
Momentary   Illuminated Push Switch Power Button 1NO 1NC With Pin Terminal
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Wenzhou, China
Brand Name: YUESHUN
Certification: CE RoHS
Model Number: LA19F-11Y
High Light:

Momentary illuminated push switch

,

1NO 1NC illuminated power button

,

Pin Terminal illuminated power button

Payment & Shipping Terms
Packaging Details: The product is packed in foam box to prevent damage during transportation.
Delivery Time: 3-7 work days
Payment Terms: T/T to our company account or by paypal
Supply Ability: 5000Pcs/Day
Specifications
Operation Type: Momentary Latching
Operating Temperature: -20℃~+55℃
Application: Universal
Contact Configuration: 1NO 1NC
Mounting Panel Thickness: 1-10 Mm
Operation Distance: About 3.1 Mm
Product Description

Power Type 12V 24V Illuminated 19mm Push Button Switch Latching Metal Push button switches



Product Description



- The LED is separate from a button. The rated voltage for button is under 250V, the voltage for LED should be choosed: 3V, 6V, 12V, 24V,36V,110V, 220V.

- We have product catalog.Please contact us on line or send an Email for sending the catalog.



Product Specification



Model Number

LA19F-11Y

Mounting Hole

19mm

Max.Switch Rating

Ith : 5A Ui : 250V AC

Material

Body Material: Stainless Steel /  Aluminum

Button Material:Stainless Steel  / Aluminum

Contact Material: Silver alloy

Base Material: PBT

The Front Shape

Flat Round Head

Terminal Type

Pin Terminal

Switch Operation

Momentary or Latching

Contact Configuration

1NO 1NC OR 2NO 2NC

Mounting panel thickness

1-10 mm

Operation Distance

About 3.1 mm

LED Parameters

Led Type: Power Symbol

LED Color:
Red,Green,Yellow,Orange,Blue,White,Purple or Double color mixing Can be customized.

Led Voltage:
3V 6V 12V 24V 36V 110V 220V 360V  for choose.

LED Life: More than 40,000 hours

Protection Level

IP67

Operating Temp

-20℃~+55℃
